42 Series Chrome
Reference:
42 Series Chrome
Features / Specifications
|
Fitting InstructionsMount bracket horizontally onto a flat surface run wires through the back and clip the lens into place. Please refer to ADR 13/00 for mounting instructions. |
| Download Data Sheet |
Technical Drawings |
Please contact our Customer Service team for all sales enquiries.Phone: 1800 815 000 |
|
| Function | Rear End Outline Marker | ||
 |
|||
| Part No. | |||
| 42CRMB | Order 42RMB and 10x42BC | ||
| . | . | ||
| LED Qty | 2 | ||
| Cable | 16cm cable | ||
| Draw | @13.8V | @28V | |
| 0.05A | 0.06A | ||
| Approvals | Function | Category | CRN |
| ADR | Rear End | 49/00 | 42839 |
| Function | Side Direction | ||
 |
|||
| Part No. | |||
| 42CAMB | Order 42AMB and 10x42BC | ||
| . | . | ||
| LED Qty | 3 | ||
| Cable | 16cm cable | ||
| Draw | @13.8V | @28V | |
| 0.05A | 0.06A | ||
| Approvals | Function | Category | CRN |
| ADR | Marker | 6/00 | 42836 |
| Function | Side Marker | ||
 |
|||
| Part No. | |||
| 42CARMB | 12-24V, Box of 10 | ||
| . | |||
| LED Qty | 2 | ||
| Cable | 16cm cable | ||
| Draw | @13.8V | @28V | |
| 0.05A | 0.06A | ||
| Approvals | Function | Category | CRN |
| ADR | Side | 45/01 | 42837 |
| Function | Front End Outline Marker | ||
 |
|||
| Part No. | |||
| 42CWMB | Order 42WMB and 10x42BC | ||
| . | . | ||
| LED Qty | 2 | ||
| Cable | 16cm cable | ||
| Draw | @13.8V | @28V | |
| 0.03A | 0.03A | ||
| Approvals | Function | Category | CRN |
| ADR | Front | 49/00 | 42840 |
