60 Series
Reference:
60 Series
Features / Specifications
|
Fitting InstructionsDrill a 10mm hole for the serrated plug. Pull the sheathed cable through the hole. Remove the protective film from the 3M tape. Push the serrated plug into the hole. Line up the lamp and press firmly. The lamp is held securely with the plug serrations and high quality 3M tape. Please refer to ADR 13/00 for mounting instructions. |
| Download Data Sheet SHOP NOW |
Technical Drawings |
Please contact our Customer Service team for all sales enquiries.Phone: 1800 815 000 |
|
| Function | Licence Lamp |
||
 |
|||
| Part No. | |||
| 60BLM | 12-24 Volt, Twin Blister | ||
| 60BLMB | 12-24 Volt, Single Bulk | ||
| . | |||
| LED Qty | 4 SMD | ||
| Cable | Blister 10cm, Bulk 50cm | ||
| Draw | @13.8V | @28V | |
| 0.03A | 0.03A | ||
| Approvals | Function | Approval No. | |
| ECE | Licence | L-E9-00.1066 | |
| CTA | Licence | CTA-060188 | |
